Projection Technology:

• System: RGB Liquid Crystal Shutter Projection System (3LCD)

Connectivity:

• USB Interface:
  • USB Type B: 1 (For Firmware Update, Copy OSD Settings)
• Analog Input:
  • D-Sub 15pin: 1
• Digital Input:
  • HDMI: 1

Projection Lens:

• Type: No Optical Zoom / Focus (Manual)
• Focal Length: 16.70 mm
• F-number: 1.44
• Zoom: 1.44 - 1.95 (Wide to Tele Ratio)
• Throw Ratio Range: 1.00 – 1.35 (Digital Zoom)

Screen Size (Projected Distance):

• Zoom (Wide): 30” to 350” [0.87 to 10.34 m]
• Zoom (Tele): 22” to 259” [0.87 to 10.34 m]

Operating Altitude:

• Range: 0 – 3,048 m (0 – 10,000 ft)

Power Features:

• Direct Power On/Off: Yes

Air Filter:

• Type: High Efficiency Filter
• Maintenance Cycle: 6,000 hours (Normal), 12,000 hours (Eco)

Brightness:

• Color Light Output: 3,300 Lumen
• White Light Output: 3,300 Lumen

Lamp Life:

• Life (Normal / Eco): 6,000 hours / 12,000 hours

Keystone Correction:

• Horizontal/Vertical: ±30 degrees

Projection System:

• Type: 3LCD
• Aspect Ratio: 4:3
• Native Resolution: XGA (1024 x 768)

Lamp Type:

• Type: 210 W UHE

Startup & Power:

• Startup Period: Up to 6 seconds
• Warm-up Period: 30 seconds
• Direct Power On / Off: Yes
